RG6 Quad Shield Coaxial Cable CATV ROSH Standard Cable 34AWG
• RG6 Coaxial Cable
• Polyethylene Insulation
• 95% braiding coverage
• Quad shield
• ROHS PVC jacket
21% conductivity copper clad steel (21%CCS).Dielectric core is
insulating grade virgin polyethylene. The 1st shield is bonded laminated aluminum tape, the 2nd shield is 95% coverage braiding, and the 3rd shield is normal aluminum foil, the fourth shield is 34AWG 0.16mm
alloy wire braiding with 95% coverage.The Jacket is PVC or PE for
RG6 tri-shield 90% coverage cable is used as a distribution cable
for indoor CATV, CCTV systems and as a connection cable for
satellite systems where lower attenuation required.
18AWG copper clad steel
Nominal diameter: 0.0403”(1.02mm)±0.01(0.0004)
Gas expanded polyethylene
Nominal diameter over dielectric: 0.18”(4.57mm)
Shield 1: Bonded aluminum laminated shielding tape
Shield 2: 0.16 aluminum braid wire,95% coverage
Maximum ovality: 0.013" (0.33)
Shield 3: Unbonded Aluminum laminated shielding tape
Screening shield: ≧85dB
Shield 4: 0.16 aluminum braid wire,95% coverage
Nominal diameter over jacket: 7.54mm± 0.2mm
Buyer's labels and cartons OEM/ODM desgin service is available.
Impedance : 75±3 ohms
Velocity of propagation: 82% nominal
- RG6 quad-shield cable has outstanding anti-interference
effectiveness and excellent transmission reliabilities.
- RG6 quad cable is of low cost, and it is easy to install as well.
- Libo cable was established in 1994, it is subsidiary of Libo group
which is one of the 500 largest private enterprises in China.
- Libo cable has a stable workforce and engineering team, lead-time
of 20’FCL is 5 days.
- Libo cable is equipped with a Provincial-level Research and
Development Center, we offer OEM and ODM services.
